Flow Chart of Pretreatment Process of Wet Processing

Pre-treatment means any treatment, which is done before the actual process. Pretreatment processes include desizing, scouring, and bleaching which make subsequent dyeing and softening processes easy. A flowchart of the pretreatment process of wet processing is given here.

Flow Chart of Pretreatment Process of Wet Processing

Level in (P.T to M.T) 60°C

Wetting agent .7g/l

Peroxide stabilizer .5g/l

Anti creasing agent.75g/l

Fabric load(10΄)

Caustic dosing (65 C*̊10́)
↓ run 5́
H2O2 dosing 70ºC *10´

Temperature rise to 105 C̊
↓ run 105 C*30̊΄PH=10.5˜11
Cooling to 78 C̊


Overflow rinse 10΄ Drain

Level in(P.T to M.T)

Acid 50ºC ˜60 C*̊10́

Peroxide killing injection 80 C*10̊΄
↓ check the residual peroxide

Overflow rinse 5΄

Acid .7g/l to maintain PH 4.5 ̃5

Bio polishing agent 1.5g/l 55ºc*(45ʹ-60´)

Sequestering agent( A.T to M.T)
↓ hot at 90 ̊C*10ʹ
Overflow rinse 10ʹ
Pretreatment Process of Wet Processing
Flow Diagram of Pretreatment
Flow Diagram of Pretreatment

The wet process is the main treatment for any type of garment washing. The wet process can be done by using different types of chemicals. The wet process section maintains a process flow chart, which facilitates the whole garments washing processes and make it easy to achieve the desired garments shade.
